M57 LOOMS

HOUSE OF TORQUE DDE 5/6 EDC16 Standalone Wiring Harness

Plug-and-Play M57 Swap Solution for Defender & Custom Conversions

Simplify your M57N/M57N2 engine swap with this standalone harness, designed for DDE5/6 ECUs (de-immobilised). Replaces factory body-side wiring for seamless integration.

The wiring loom supplied has 7 connectors:
1. Plug for the Body Loom
2. ECU Connector
3. Throttle Pedal (BMW)
4. Earth Ring
5. ECU supply & Ground
6. OBD II Connector (For diagnostic purposes)
7. CANbus connection
8. Fuel pump relay connector

SUIT DONER ENGINES FROM: E53, E70, E60, E90 E83 (M57N + M57N2 ENGINES ONLY)

Key Features

✅ Direct Connections For:

• DDE5/6 ECU (de-immobilised)
• BMW throttle pedal (Check the connector is correct for your pedal)
• OBD port (diagnostics)

✅ Critical Outputs Included:

• Inline fuel pump control
• CANBUS interface (for 6HP/8HP transmissions or other CAN devices)
• Oil light circuit *

✅ Power Requirements:

• Ignition supply
• Permanent 12V supply
• Battery negative

Installation Notes

⚠️Competent Wiring Knowledge Recommended. Please read the instructions to aid your judgement

• Main relay wiring not included – Follow provided guide for correct setup
• * Oil light output is ECU dependent and we would recommend wiring your oil light directly to the switch on the engine
• Detailed fitting instructions below

Why Choose This Harness?

✔ Saves Fabrication Time – Pre-terminated for plug-and-play use
✔ OBD Retention – Maintain diagnostic capability
✔ CANBUS Ready – Simplified transmission/device integration

Installation instructions: Click Here

tags: m57 swap Australia, m57 swap standalone, m57 swap defender

Simplify your transmission swap with the HOUSE OR TORQUE purpose-built standalone wiring harness, designed to integrate BMW’s ZF 6-speed automatics (6HP26/28) into custom vehicle applications—from Land Rover Defenders to Transit vans and beyond.

Key Features & Compatibility

✅ Direct Connections For:

• ZF 6HP26/26X (E53 X5)
• ZF 6HP28/28X (E70 X5)
• Shifter, Engine ECU CANBus, and plug-in CANBus resistors

✅ Universal Design:

• Extra length for versatile fitment (Defenders, Transit vans, etc.)
• Includes +12V, ground, and ignition connections

This HOUSE OF TORQUE loom covers the wiring side only, the CANbus must still be connected to a compatible ECU or controller.

Technical Notes

• Skill Level: Requires basic automotive electrical knowledge for power/ground connections.
• Included: Harness, CANBus resistors, and downloadable fitting guide.
• Not Included: Transmission, shifter, or vehicle-specific power taps.
• BRAKE SIGNAL CONVERTER required when retaining the original brake switch, unless suitable brake-signal conversion has been already sorted. SEE HERE

Whilst every effort has been made to provide detailed instructions to make the loom as straightforward as possible to fit, it still relies on a reasonable working knowledge of vehicle electrics in order to find and safely connect to power and ground sources. We have included the fitting instructions below to aid your judgement.

Installation instructions: Click here

implified Integration for Non-BMW Pedal Boxes

Eliminate compatibility issues when connecting aftermarket or non-BMW brake switches to BMW ECUs (DDE systems).

Key Features

✔ Universal Inputs – Accepts standard +12V brake switch
✔ BMW-ECU Outputs – Converts to proper signals for:

• Cruise control cancellation
• Transmission integration
• Engine management functions
  ✔ Compact Design – Easily mounts near pedal box or ECU

Installation:

1. Connect input side to existing brake switch signal, and ground.
2. Route outputs to BMW ECU brake signal wires

BMW M57 Fuel Pump Loom – Complete Relay Kit

Connect your BMW inline fuel pump during an M57 conversion with this House of Torque loom. Supplied as the complete relay kit for a tidy fuel pump wiring installation.

Included

• 2-metre fuel pump loom with OEM pump connector
• Pre-wired relay block with Durite relay
• Fuse holder

Compatibility & Installation

Designed for BMW inline fuel pumps such as the E53 X5 type. Check your pump connector before ordering.

Can be used with the House of Torque DDE5/6 standalone harness. ECU-controlled pump switching applies to DDE5. For DDE6, House of Torque recommends an ignition-controlled feed because ECU activation may not work. Follow the fitting guide for the correct relay switching arrangement.

Installation requires competent automotive wiring skills. Fuel pump not included. This listing is for the complete loom and relay kit only.

Download fuel pump relay fitting instructions (PDF)

Fusion Fab IAT sensor extension for M57N

• Saves cutting and extending your IAT sensor wiring to reach either an EGR Delete kit, or your intercooler to Intake manifold pipework

NOTE: Does not suit N2 IAT SENSORS!!

M57 Vacuum-to-Electronic Turbo Conversion Loom

Upgrade your vacuum-controlled M57/M57N to a later electronically controlled M57N/M57N2 turbo with this high-quality, plug-and-play conversion loom.

The later M57N2 V-band turbo offers a more efficient, freer-flowing design, with a substantially larger turbine housing, a larger dump-pipe outlet and an improved inlet. This loom provides a straightforward wiring solution for fitting that turbo to your vacuum-controlled M57/M57N engine.

Features

• Plug-and-play connections – Connects directly to the factory harness and compatible electronic turbo actuator, with no cutting or splicing required.
• Secure grounding – Includes the necessary ring terminal for connection to a clean, secure chassis earth.
• High-temperature protection – Protected wiring suited to the engine-bay environment.

Why Upgrade?

• More direct actuator response – Removes reliance on the vacuum-operated turbo-control system and its associated delays.
• Eliminates turbo-control vacuum leaks – Removes the brittle vacuum hoses associated with vacuum actuator operation.
• Reliable operation in demanding conditions – Reduces reliance on vacuum-control components that can cause problems in wet, muddy environments.
• Hybrid-turbo ready – Suitable for compatible hybrid turbo builds using the supported electronic actuator system.

A straightforward loom solution for your vacuum-to-electronic M57 turbo upgrade.

--PLEASE NOTE: ECU RECALIBRATION IS REQUIRED TO COMPLETE THE CONVERSION - ECU SERVICE

Defender TDCI to BMW Throttle Pedal Adapter

Plug-and-Play Drive-by-Wire Integration

This 260mm adapter enables Land Rover Defender TDCI throttle pedals to connect directly to BMW pedal connectors, specifically designed for use with House of Torque standalone looms.

Key Details:

• 260mm Length – Ideal for flexible mounting
• Plug-and-Play – No splicing or wiring modifications
• Robust Construction – OEM-grade materials for durability

Compatibility:
✔ Converts Defender TDCI pedal to BMW pedal connector
✔ House of Torque standalone loom integration

Installation:

• Requires basic mechanical fitting
• No coding or electrical work needed
